New HOWO TX Single-Bridge Crane Truck | Weichai 270HP | Changxing 8T 5-Section Boom
New HOWO TX Single-Bridge Crane Truck — Weichai 270HP · Changxing 8T 5-Section Boom
Announcement Information
- Vehicle Announcement No.: ABC5186JSQZZ6
- Chassis Announcement No.: ZZ1187K501GF1
Chassis Core Specifications
- Engine: Weichai WP7H270E62, 270HP, 6.8L displacement
- Gearbox + PTO: HW95508STC2 gearbox + HW45ZC flange-type PTO
- Wheelbase: 5000mm / 4500mm (optional)
- Axle Ratio: 5.29
- Front Axle: HOWO 7.5T front axle
- Rear Axle: 13T engineering-grade rear axle
- Frame: Three-layer frame (8+4+4 / 300mm)
- Leaf Springs: Front 11/9-leaf, Rear 8-leaf
- Tires: 10.00R20 (mixed tread / 18PR)
Cab Configuration
- TX-D cab (extended sleeper) — Woying Edition
- Multi-function steering wheel
- Electric heated rear-view mirrors
- Driver airbag + co-driver basic seat
- Middle seat in cab
- 10.1-inch full HD LCD infotainment screen (MP5)
- Center bumper (full metal)
- Sun visor
- AEBS + ABS (4S/4M) + ESC active safety systems
- 200L fuel tank
- Manual lift
- Optional: under-cab start/stop switch
Upper Structure — Changxing Crane
- Brand: Changxing
- Rated Lifting Capacity: 8 tonnes
- Boom Sections: 5-section (2nd section single-extension)
- Max Boom Length: 18.5 m
- Max Lifting Height: 19.8 m
- Rotation: Double rotation
- Outriggers: Double-section outriggers
- Winch: Cycloid motor winch
- Main Beam: Full-through beam
Cargo Box
- 5.9 m side-three bottom-five cold-riveted engineering cargo box
