Item Specification
Chassis Dongfeng D1L Single-row Cab

Factory air suspension seat, multifunctional steering wheel, factory air conditioner

Yuchai 170HP engine, Fast 8-speed transmission

4500mm short wheelbase, three-layer frame beam (7+4+5mm)

825 steel radial tires, 7-ton reinforced rear axle

Vehicle curb weight: 9920Kg (excluding accessories)
Superstructure 6-ton One-tow-two wrecker body with sunken structure

Overall flatbed length: 6.5m (including hydraulic tilting section), width: 2.55m

14mm solid steel frame with holes

Dense cross beams and reinforced diagonal supports underneath

5mm thick wear-resistant checkered plate for flatbed floor, double subframe design

110-type main cylinder & 110-type lifting cylinder

10mm thick manganese steel slideway

6-ton horizontal winch, 6-ton two-section rear lifting arm (frame-mounted)
Crane Changxing 6.3-ton 4-section boom crane

Boom length: 12.5m

Top control (bottom control optional)
Accessories 1 pair of auxiliary trolleys, 1 pair of triangular wheel stoppers

4 heavy-duty lashing straps, 1 crowbar
